SHND69800ANGTH
$8,494.19
Out of stock
SKU
SHND69800ANGTH
SHND 800 Amp, 600V, Circuit Breaker, Siemens SHND69800ANGTH, SHND 800A | aka: ITE SHND69800ANGTH, ITE Siemens SHND69800ANGTH, UPC:
SHND 800 Amp, 600V, Circuit Breaker, Siemens SHND69800ANGTH, SHND 800A | aka: ITE SHND69800ANGTH, ITE Siemens SHND69800ANGTH, UPC:
Description:
- Siemens SHND69800ANGTH, SHND 800 Amp, 600V, Circuit Breaker, SHND 800A | aka: ITE SHND69800ANGTH, ITE Siemens SHND69800ANGTH, UPC:
- Bolt On Mounting
- Frame Type: SHND
- Dimensions: 7.5 Inch Wide x 11 Inch High x 5.44 Inch Deep
- Weight: 20lbs.
- Complete with: Long Time, Short Time, Instantaneous and Ground Fault Trip Functions
- Wire Size: Lug Kit TA2J6500 (3/0 AWG to 500 Kcmil)
- SHND, 800A, 600V AC, 3 Pole
- 100% Rated
- High Interrupting
- Interrupting Rating at 240 Volts AC: 100,000
- Interrupting Rating at 480 Volts AC: 65,000
- Interrupting Rating at 600 Volts AC: 35,000
- Thermal Magnetic
