LLSRK-300ID

$213.39
Stock Quantity: 3
SKU
LLSRK-300ID
LLSRK 300 Amp, 600V, Class RK1, Littelfuse LLSRK-300ID, LLSRK 300A | aka: Time Delay LLSRK-300ID, Littel fuse LLSRK-300ID, UPC:
Allfuses.com is not an authorized distributor of Littelfuse products

LLSRK 300 Amp, 600V, Class RK1, Littelfuse LLSRK-300ID, LLSRK 300A | aka: Time Delay LLSRK-300ID, Littel fuse LLSRK-300ID, UPC:


Description:

  • 300 Amps, 600 Volts AC
  • UL Class RK1 Fuse w/ Indicator
  • Time Delay
  • Dual Element
  • Physical Size: 2 19/32" x 11 5/8"
  • Extremely Current Limiting
  • IEC Type 2 protection to IEC and NEMA Type Motor Starters
  • For Use with All General Purpose Circuits
  • AC Voltage Rating: 600
  • DC Voltage Rating: 300
  • Interrupting Rating: 200,000 AIC @ 600VAC
  • DC Interrupting Rating: 20,000 AIC @ 300VDC

  • Related Products:

  • Fuse Blocks
  • Box Side Clip (Al/Cu 1000-250kcmil)
  • 1 Pole: 64001R 3 Pole: 64003R
  • Box Side Clip (Al/Cu 2 Hole - 350kcmil-#6)
  • 3 Pole: 64033R

  • Fuse Reducers
  • 600 Amp to 400 Amp: R642
Data Sheet
