JLLS-080P

$36.59

Stock Quantity: 25

SKU

JLLS-080P

JLLS 80 Amp Silver Plated, 600V, Class T, Littelfuse JLLS-080P, JLLS 80A Silver Plated| aka: Very Fast Acting JLLS-080P, Littel fuse JLLS-080P, UPC: 07945882171

See More JLLS See More Littelfuse

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Allfuses.com is not an authorized distributor of Littelfuse products

Details

JLLS 80 Amp Silver Plated, 600V, Class T, Littelfuse JLLS-080P, JLLS 80A Silver Plated| aka: Very Fast Acting JLLS-080P, Littel fuse JLLS-080P, UPC: 07945882171

Description:

80 Amps, 600 Volts AC
UL Class T Fuse
Very Fast Acting
Silver Plated
Current Limiting
Physical Size: 13/16" x 2 61/64"
Compact Design
Variable Speed Drive Protection
AC Voltage Rating: 600
DC Voltage Rating: 300
Interrupting Rating: 200,000 AIC @ 600VAC
DC Interrupting Rating: 20,000 AIC
RoHS Compliant
UL Listed (File: E81895) CSA Certified (File: LR29862)

Related Products:

Fuse Blocks
Box Lugs (Al/Cu 2/0 -#6)
1 Pole: 61031T 2 Pole: 61032T 3 Pole: 61033T
