NOS-15

$11.64
Stock Quantity: 61
SKU
NOS-15
NOS 15 Amp, 600V, Class K5, Bussmann NOS-15, NOS 15A | aka: Cooper Bussmann NOS-15, Eaton NOS-15, UPC: 051712310154
Allfuses.com is not an authorized distributor of Bussmann products

NOS 15 Amp, 600V, Class K5, Bussmann NOS-15, NOS 15A | aka: Cooper Bussmann NOS-15, Eaton NOS-15, UPC: 051712310154


Description:

  • 15 Amps, 600 Volts AC
  • One Time Fuse
  • General Purpose
  • Ferraz OTS Style are Much Less Expensive
  • Physical Size: 0.81" x 5"
  • AC Voltage Rating: 600
  • Interrupting Rating: 50,000 AIC RMS @ 600VAC
  • Class K5 (0-60A), Std. 248-9 Class H (70-600A), Std. 248-6
  • UL Guide JDDZ, File E4274
  • CSA Certified, Class 1421-01, File 53787

  • Related Products:

  • Fuse Blocks
  • Non-Spring Reinforced, Box Lugs (Al/Cu #2-14)
  • Adder: 60300 1 Pole: 60301 2 Pole: 60302 3 Pole: 60303
  • Spring Reinforced, Box Lugs (Al/Cu #2-14)
  • Adder: 60305 1 Pole: 60306 2 Pole: 60307 3 Pole: 60308
  • Non-Spring Reinforced, Screw Connector (Cu #10-14)
  • 1 Pole: 60311 3 Pole: 60313
  • Spring Reinforced, Screw Connector (Cu #10-14)
  • 3 Pole: 60318
  • Spring Reinforced, Pressure Plate (Cu #10-14)
  • 3 Pole: 60328

  • FuseReducers
  • 60 Amp to 30 Amp: 636
  • 100 Amp to 30 Amp: 162

Data Sheet
