JTD-100ID

$63.09
Stock Quantity: 612
SKU
JTD-100ID
JTD 100 Amp, 600V, Class J, Littelfuse JTD-100ID, JTD 100A | aka: Time Delay JTD-100ID, Littel fuse JTD-100ID, UPC: 079458031799
Allfuses.com is not an authorized distributor of Littelfuse products

JTD 100 Amp, 600V, Class J, Littelfuse JTD-100ID, JTD 100A | aka: Time Delay JTD-100ID, Littel fuse JTD-100ID, UPC: 079458031799


Description:

  • 100 Amps, 600 Volts AC
  • UL Class J Fuse w/ Indicator
  • Time Delay
  • Dual Element
  • Physical Size: 1 1/8" x 4 5/8"
  • Current Limiting
  • IEC Type 2 Protection
  • AC Voltage Rating: 600
  • DC Voltage Rating: 300
  • Interrupting Rating: 200,000 AIC @ 600VAC
  • DC Interrupting Rating: 20,000 AIC
  • UL Listed (File: E81895) CSA Certified (File: LR29862)

  • Related Products:

  • Fuse Blocks
  • Spring Reinforced, Box Side Clip (Al/Cu 2/0-#6)
  • 3 Pole: 61008SJ
  • Spring Reinforced, Box Lugs (Al/Cu 2/0-#6)
  • 1 Pole: 61036J 2 Pole: 61037J 3 Pole: 61038J
  • Spring Reinforced, Box (Cu 2/0-#12)
  • 3 Pole: 61008J

  • Fuse Reducers
  • 600 Amp to 100 Amp: J616
  • 400 Amp to 100 Amp: J416
  • 200 Amp to 100 Amp: J216
Data Sheet
