AJT80N

$45.34

Out of stock

SKU

AJT80N

AJTN 80 Amp, 600V, Class J, Ferraz AJT80N, AJT-N 80A | aka: Mersen AJT80N, Ferraz Shawmut AJT80N, UPC: 782001497804

See More AJT See More Ferraz Shawmut

Allfuses.com is not an authorized distributor of Ferraz Shawmut products

AJTN 80 Amp, 600V, Class J, Ferraz AJT80N, AJT-N 80A | aka: Mersen AJT80N, Ferraz Shawmut AJT80N, UPC: 782001497804

80 Amps, 600 Volts AC

UL Class J Fuse

Time Delay for Motor Starting and Transformer Inrush

Non Indicating

Extremely Current Limiting

Most Current Limiting UL Class Fuse

Recommended for Arc Flash Energy Reduction

Physical Size: 1 1/16" x 4 5/8"

Metal Embossed Date and Catalog Number for Lasting Identification

AC Voltage Rating: 600

DC Voltage Rating: 500

AC Interrupting Rating: 200,000 AIC

DC Interrupting Rating: 100,000 AIC

UL Listed to Standard 248-8 File E2137

DC Listed to UL Standard 248

CSA Certified to Standard C22.2 No. 248.8

IEC 269-2-1

Related Products:

Fuse Blocks

Spring Reinforced, Box Side Clip (Al/Cu 2/0-#6)

3 Pole: 61008SJ

Spring Reinforced, Box Lugs (Al/Cu 2/0-#6)

1 Pole: 61036J 2 Pole: 61037J 3 Pole: 61038J

Spring Reinforced, Box (Cu 2/0-#12)

3 Pole: 61008J

Fuse Reducers

600 Amp to 100 Amp: J616

400 Amp to 100 Amp: J416

200 Amp to 100 Amp: J216
