A6T3

$13.74
Stock Quantity: 40
SKU
A6T3
A6T 3 Amp, 600V, Class T, Ferraz A6T3, A6T 3A | aka: Mersen A6T3, Ferraz Shawmut A6T3, UPC: 782001891015
Allfuses.com is not an authorized distributor of Ferraz Shawmut products

A6T 3 Amp, 600V, Class T, Ferraz A6T3, A6T 3A | aka: Mersen A6T3, Ferraz Shawmut A6T3, UPC: 782001891015


Description:

  • 3 Amps, 600 Volts AC
  • UL Class T Fuse
  • Fast Acting
  • Extremely Current Limiting
  • Physical Size: 0.57" x 1.5"
  • AC Voltage Rating: 600
  • DC Voltage Rating: 300
  • AC Interrupting Rating: 200,000 AIC
  • DC Interrupting Rating: 100,000 AIC
  • Unique Dimensions Prevent Replacement by Other Fuse Classes
  • Blade Stamped Catalog Numbers for Permanent Identification
  • Small Physical Size for Greater Design Flexibility
  • UL Listed to Standard 248-15; UL File E2137
  • CSA Certified to Standard C22.2 No. 248.15
  • DC Listed to UL Standard 248

  • Related Products:

  • Fuse Blocks
  • Box Lugs (Al/Cu #2-14)
  • 1 Pole: 60306T 2 Pole: 60307T 3 Pole: 60308T
  • Pressure Plate (Cu #10-14)
  • 1 Pole: 60326T 2 Pole: 60327T 3 Pole: 60328T

Data Sheet
