A70Q250-4

$172.24
Stock Quantity: 1
SKU
A70Q250-4
A70Q 250 Amp, 700V, Semiconductor, Ferraz A70Q250-4, A70Q 250A | aka: Mersen A70Q250-4, Ferraz Shawmut A70Q250-4, UPC: 782001140991
Allfuses.com is not an authorized distributor of Ferraz Shawmut products

A70Q 250 Amp, 700V, Semiconductor, Ferraz A70Q250-4, A70Q 250A | aka: Mersen A70Q250-4, Ferraz Shawmut A70Q250-4, UPC: 782001140991


Description:

  • 250 Amps, 700 Volts AC
  • Semiconductor Fuse
  • Extremely Fast Acting
  • Current Limiting
  • Physical Size: 2" x 5.09"
  • AC Voltage Rating: 700
  • DC Voltage Rating: 650
  • AC Interrupting Rating: 100,000 AIC
  • DC Interrupting Rating: 100,000 AIC
  • Solid Fill Technology for Extra Reliability in Performance
  • Most Responsive Protection for Applications Not Required to Sustain Heavy Overloads
  • Developed for Inverter Applications Requiring Extremely Low I²t
  • UL Recognized Component UL File E60314
  • AC: Guide No. JFHR2
  • DC Tested to UL Standard 198L Parameters (35-600A)

  • Fuse Block
  • Stud Mount (1 Pole): P266A

Data Sheet
